Key Benefits for Industrial & Security Projects
1. Stable 24 V AC for Professional Security Equipment
24 V AC is the standard supply for many professional CCTV and PTZ domes, video doorbells and access devices. MKAC-57-242200M delivers a regulated 24 V AC / 2.2 A (57.6 W max) output, giving sufficient headroom for high-speed PTZ movement, IR illumination and heater/fan modules inside outdoor housings.
2. Wide Temperature Range for Harsh Environments
Designed for industrial and semi-outdoor applications, the unit operates reliably from –30℃ to +35℃. This allows stable performance in cold regions, equipment rooms, outdoor enclosures and exposed ceiling spaces where temperature can fluctuate significantly.
3. Built-in Protection for Field Reliability
To protect both the power supply and connected devices, MKAC-57-242200M integrates:
- OCP – Over-Current Protection
- OVP – Over-Voltage Protection
- SCP – Short-Circuit Protection
These protections reduce the risk of device damage, wiring faults and on-site failures, helping integrators lower maintenance cost and truck rolls.
4. Industrial-Grade Construction
With a rugged AC cable input and a compact, enclosed metal housing (approx. 99.5 × 82 × 67 mm, 1120 g), the power supply is suitable for mounting in junction boxes, control cabinets and ceilings near cameras or access devices.
5. Certified & Export-Ready
MKAC-57-242200M is certified to major international safety and EMC standards, including UL62368, EN62368, FCC Part 15, EN55032 and GB4943.1, making it easier for your finished product or system to pass compliance checks, audits and customs inspection in key markets.
6. Energy-Efficient 24 V AC Supply (EU Level VI)
Thanks to its high-efficiency design, the adapter meets EU Level VI energy-efficiency requirements, reducing wasted power and heat generation – especially important for equipment that runs continuously in security and industrial environments.
Technical Specifications
- Model: MKAC-57-242200M
- Input Voltage: 220 V AC
- Input Frequency: 50 Hz
- Input Connector: AC cable input
- Output Voltage: 24 V AC
- Output Current: 2.2 A (2200 mA)
- Maximum Output Power: 57.6 W
- Operating Temperature: –30℃ to +35℃
- Protection Features: OCP (Over-Current), OVP (Over-Voltage), SCP (Short-Circuit)
- Dimensions: 99.5 × 82 × 67 mm
- Product Weight: 1120 g
- Safety / EMC Standards: UL62368, EN62368, FCC Part 15, EN55032, GB4943.1
Request a Quote
If you need a reliable 24 V AC, 57.6 W power supply for PTZ cameras, access-control systems or industrial equipment, MKAC-57-242200M is a proven choice.
Share your project details — device power requirements, installation environment and target market — and our team will recommend the suitable configuration and provide a competitive quotation.
You can fill in the inquiry form on this page or contact us directly by email or WhatsApp for a fast response.
