Designed for the stringent safety requirements of the healthcare industry, our 5V Medical Power Supply (Internal Ref: MC5C-050120c) provides reliable, low-noise DC power for portable and handheld medical devices. Unlike standard consumer USB chargers, this unit is engineered with medical-grade isolation to protect both patients and operators from electrical hazards.
This adapter is an ideal solution for OEM manufacturers needing a compliant power source for home healthcare devices ("Home Care") or clinical monitoring equipment. It combines compact form factor with robust circuit protection, ensuring your device passes compliance testing smoothly.
Key Features & Safety
- Medical Grade Safety: Fully compliant with IEC/EN 60601-1 (3rd/4th Edition) standards, featuring 2xMOPP (Means of Patient Protection) insulation logic.
- Stable 5V Output: Delivers a precise 5V DC output with low ripple noise, preventing interference with sensitive sensors or microprocessors in diagnostic tools.
- Energy Efficiency: Meets DoE Level VI energy efficiency standards, ensuring cool operation and low standby power consumption.
- Leakage Current Protection: Extremely low leakage current (< 100µA), making it safe for devices used in close proximity to patients.
- Compact Design: Wall-mount style (plug-in) design saves space and is easy to transport for portable applications.
Target Applications
- Portable Monitors: Blood pressure monitors, glucometers, and pulse oximeters.
- Therapeutic Devices: Portable nebulizers, TENS units, and pain relief devices.
- Diagnostic Tools: Digital thermometers and handheld otoscopes.
- Consumer Medical: Breast pumps and electric grooming aids suitable for hospital use.
Technical Specifications
(Note: Final specs depend on your selected configuration)
- Input Voltage: 90-264VAC, 50/60Hz (Universal)
- Output Voltage: 5V DC
- Output Current: [Confirm: e.g., 1.2A / 2.0A]
- Connector Type: [Options: Micro-USB, USB-C, DC Barrel 5.5x2.1mm, etc.]
- Safety Approvals: UL, cUL, CE, FCC, IEC 60601-1
- MTBF: > 100,000 hours at full load
OEM & Customization Support
We understand that medical devices often require specific connector fitments.
- Custom Cable Lengths: From 1.2m to 3m+
- Connector Variations: Right-angle, straight, or custom molded plugs.
- Branding: Private label printing available for bulk orders.
Secure Your Supply Chain Avoid the risk of using non-certified consumer chargers for medical applications. We offer consistent lot quality and long-term availability.
